Dell PowerEdge R750xa 2U GPU Server | Configure to Order
PowerEdge R750xa
Dell
Dell PowerEdge R750xa - dual-socket 2U GPU acceleration platform
A 2U rack server built specifically for accelerated computing, the R750xa carries up to four double-width 300 W GPUs in the front chassis plus two single-width 75 W cards at the rear, all fed by up to eight PCIe Gen4 slots.
Two 3rd Generation Intel Xeon Scalable processors of up to 40 cores each drive eight memory channels per socket across 32 DDR4 DIMM slots at speeds to 3200 MT/s, with RDIMM capacity to 2 TB and LRDIMM to 4 TB. Intel Optane Persistent Memory 200 series is supported in up to 16 slots.
Front storage runs to eight 2.5-inch SAS/SATA/NVMe bays, or six direct-attach NVMe SSDs, behind PERC H745, H755, H755N, H345, HBA355i or software RAID. BOSS-S2 provides a mirrored pair of M.2 SSDs for the hypervisor or operating system, keeping the front bays free for data.
Management is iDRAC9 with Redfish, telemetry streaming and OpenManage Enterprise integration; security includes Silicon Root of Trust, Secure Boot, signed firmware and System Lockdown. Air cooling is standard with optional direct processor liquid cooling.
Every R750xa is configured to order: choose processors, DIMM population, drive bays and controller, GPU loadout, OCP 3.0 networking, power supplies and rail kit before it ships.
All hard drives are tested to 100% health · All SSDs are tested to 90-100% health
No matches found.
Share or save this configuration
No components selected yet.
Required options not yet complete
Contact Us About StockAbout the Dell PowerEdge R750xa
The PowerEdge R750xa is Dell's GPU-first 2U platform: four double-width 300 W accelerators in the front of the chassis, two more single-width cards at the rear, and up to eight PCIe Gen4 slots to connect them all to two 3rd Generation Intel Xeon Scalable processors.
Thirty-two DDR4 DIMM slots across eight channels per socket carry up to 4 TB at 3200 MT/s, with Intel Persistent Memory 200 series supported in up to 16 slots. Front storage runs to eight 2.5-inch SAS/SATA/NVMe bays or six direct-attach NVMe SSDs, and the BOSS-S2 module keeps the hypervisor on a mirrored pair of M.2 SSDs rather than a data bay.
Use the configurator below to specify processors, memory, backplane and controller, GPUs, networking and power supplies. Everything is built and tested to that specification before it leaves us.
Typical Use Cases
- AI and machine learning training nodes running four double-width NVIDIA accelerators under PyTorch or TensorFlow
- Inference serving where several single-width 150 W cards give better throughput per rack unit than fewer large GPUs
- HPC compute nodes in Slurm-scheduled clusters, with Gen4 x16 slots left free for InfiniBand or high-speed Ethernet HCAs
- VDI and virtual workstation hosts using vGPU profiles under VMware ESXi or Citrix Hypervisor
- Containerised GPU workloads on Kubernetes with the NVIDIA device plugin and MIG partitioning
- Rendering, simulation and CAE farms needing large host memory alongside accelerator capacity
- Data science platforms combining RAPIDS or Spark with direct-attach NVMe for local dataset staging
- General dual-socket virtualisation where the 32 DIMM slots and PCIe Gen4 headroom matter more than drive count
Key Specifications
| Processor | |
|---|---|
| Processor Family | 3rd Generation Intel Xeon Scalable |
| No of Processors | Up to two |
| Cores Per Processor | Up to 40 cores per processor |
| Memory | |
| Memory Type | DDR4 |
| Memory Slots | 32 DDR4 DIMM slots |
| Maximum Memory | 2 TB max (RDIMM) or 4 TB max (LRDIMM) |
| Memory Speed | Up to 3200 MT/s |
| RAM Type | Registered ECC DDR4 DIMMs |
| Storage Controllers | |
| Internal controllers | PERC H745, HBA355I, S150, H345, H755, H755N |
| Software RAID Controller | Boot Optimized Storage Subsystem (BOSS-S2): HW RAID 2 x M.2 SSDs 240 GB or 480 GB |
| External Controller | PERC H840, HBA355E |
| Storage | |
| Drive Bays 2.5 inch | Up to 8 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) |
| Drive Bays 3.5 inch Max Capacity | 122.88 TB |
| NVMe PCIe | Up to 6 x 2.5-inch NVMe (SSD) direct-attach max 92.1 TB |
| Power | |
| Power Supply Options | 1400 W Platinum AC/240 mixed mode, 1800 W Titanium HLAC/240 mixed mode, 2400 W Platinum AC/240 mixed mode, 2800 W Titanium HLAC/240 mixed mode |
| Chassis | |
| Form Factor | 2U rack server |
| Chassis Width | 482 mm (18.97 inches) |
| Chassis Depth (3.5 inch HDD) | 894.8 mm (35.22 inches) - without bezel, 908.64 mm (35.77 inches) - with bezel |
| Expansion Slots | |
| PCIe Configuration | Up to 8 x PCIe Gen4 slots (up to 6 x16 + 2 x8) |
| Networking | |
| Network Interface | 2 x 1 GbE LOM |
| I/O Ports | |
| Front USB Ports | 1 x USB 2.0 |
| Rear Ports | 1 x USB 2.0, 1 x Serial (optional), 1 x USB 3.0, 2 x RJ-45, 1 x VGA (optional for liquid cooling configuration) |
| Management | |
| Embedded Management | iDRAC9, iDRAC Service Module, iDRAC Direct, Quick Sync 2 wireless module |
| Security | |
| TPM | TPM 1.2/2.0 FIPS, CC-TCG certified, TPM 2.0 China NationZ |
| Security Features | Cryptographically signed firmware, Secure Boot, Secure Erase, Silicon Root of Trust, System Lockdown (requires iDRAC9 Enterprise or Datacenter) |
