SuperMicro 2029BT-HNC1R 2U 4-Node Server
2029BT-HNC1R
SuperMicro
SuperMicro SuperServer 2029BT-HNC1R – 2U 4-Node Twin Server
The 2029BT-HNC1R packs four independent, hot-pluggable server nodes into a single 2U chassis, each running its own dual-socket motherboard, memory pool and storage bays. It's Supermicro's answer to hosting providers who need to squeeze maximum compute density out of limited rack space without sacrificing per-node redundancy.
Each node takes two LGA 3647 2nd Gen Intel Xeon Scalable processors (Cascade Lake or Skylake) with up to 28 cores apiece, backed by 24 DIMM slots supporting up to 6TB of DDR4-2933 RDIMM or LRDIMM, with Optane DCPMM support on Cascade Lake parts.
Storage per node is flexible: six SAS3 hot-swap 2.5" bays, or four NVMe plus two SAS3, driven by an onboard Broadcom 3108 controller with hardware RAID 0/1/5/6/10/50/60. Networking runs through a mandatory SIOM card slot, keeping fabric choice open per deployment.
At Compuwyze you configure each node's CPU pairing, memory footprint, drive bay mix and SIOM network card to match the workload, whether that's dense virtualisation, hyperconverged storage, or straight HPC throughput.
All hard drives are tested to 100% health · All SSDs are tested to 90-100% health
Normally available from . These chassis are out of stock at the moment:
No matches found.
Share or save this configuration
No components selected yet.
Required options not yet complete
Contact Us About StockAbout the SuperMicro 2029BT-HNC1R
Four independent dual-socket nodes in a single 2U chassis, the 2029BT-HNC1R is built for operators who measure success in cores and VMs per rack unit. Configure each node's processors, memory, storage bays and SIOM network card below to match your workload.
Built for density-driven infrastructure
With up to 28 cores per socket, 6TB of DDR4 per node and flexible SAS3/NVMe storage, this platform suits hosting providers and hyperconverged deployments where per-U compute density matters more than any single feature. Each node is configured and tested independently, so what you order is what gets racked.
Typical Use Cases
- Hosting providers deploying dense multi-tenant virtual machine clusters
- Hyperconverged infrastructure nodes running vSAN, Storage Spaces Direct or Ceph
- HPC compute clusters where core density per rack unit is the limiting factor
- Cloud service providers scaling out identical node pools
- Kubernetes worker node fleets requiring predictable per-node specification
- Data centre consolidation projects replacing multiple 1U single-node servers
- Batch processing, rendering and simulation workloads across many parallel nodes
Key Specifications
| Chassis | |
|---|---|
| Form Factor | 2U Rackmount |
| Model | CSE-217BHQ+-R2K22BP2 |
| Width | 17.6" (447mm) |
| Height | 3.47" (88mm) |
| Depth | 28.75" (730mm) |
| Gross Weight | 85 lbs (38.6kg) |
| Net Weight | 54.5 lbs (24.7 kg) |
| Processor | |
| Socket Type | Dual Socket P (LGA 3647) |
| Supported Processors | 2nd Gen Intel® Xeon® Scalable Processors and Intel® Xeon® Scalable Processors |
| UPI Speed | Dual UPI up to 10.4GT/s |
| CPU TDP Support | 70-205W |
| Maximum Cores | Up to 28 Cores |
| Memory | |
| DIMM Slots | 24 DIMM slots |
| Maximum Capacity | Up to 6TB 3DS ECC DDR4-2933MHz RDIMM/LRDIMM |
| Supported Memory Types | 2933/2666/2400/2133MHz ECC DDR4 RDIMM/LRDIMM, Intel® Optane™ DCPMM |
| Storage Controllers | |
| Chipset | Intel® C621 chipset |
| SATA Ports | SAS3 (12Gbps) via Broadcom 3108; RAID 0, 1, 5, 6, 10, 50, 60 |
| Hot-swap Drive Bays | 6 Hot-swap 2.5" SAS3 drive bays or 4 NVMe + 2 SAS3 Hot-swap 2.5" |
| M.2 Slots | 2 M.2 NVMe or SATA (2240/2260/2280) |
| SATA DOM Support | 1 SuperDOM (Disk on Module) port; M.2 and SATA DOM for boot drive only |
| Networking | |
| Network Ports | 1 RJ45 Dedicated IPMI LAN port; Must bundle with at least one SIOM network card |
| Management | |
| IPMI | Support for Intelligent Platform Management Interface v.2.0; IPMI 2.0 with virtual media over LAN and KVM-over-LAN support |
| Graphics | ASPEED AST2500 BMC; 1 VGA port |
| Management Software | Intel® Node Manager, IPMI 2.0, KVM with dedicated LAN, SSM, SPM, SUM, SuperDoctor® 5 |
| BIOS Type | |
| BIOS Type | AMI 32Mb SPI Flash ROM |
| Expansion Slots | |
| PCI-Express Slots | 1 PCI-E 3.0 (x16) Low-profile slot; 1 SIOM card support |
| USB Ports | 2 USB 3.0 ports (rear) |
| Video Ports | 1 VGA port |
| System Cooling | |
| Fans | 4 Heavy duty 8cm PWM fans with air shroud |
| Power | |
| Power Supply | 2200W Redundant Power Supplies with PMBus |
| AC Input | 1200W: 100-127Vac / 50-60Hz; 1800W: 200-220Vac / 50-60Hz; 1980W: 220-230Vac / 50-60Hz; 2090W: 230-240Vac / 50-60Hz; 2090W: 180-220Vac (for UL/cUL only); 2200W: 220-240Vac (for UL/cUL only); 2090W: 230-240Vdc (for CCC only) |
| +12V Output | Max: 100A (100-127Vac); Max: 150A (200-220Vac); Max: 165A (220-230Vac); Max: 174.17A (230-240Vac); Max: 174.17A (180-220Vac, UL/cUL only); Max: 183.33A (220-240Vac, UL/cUL only); Max: 174.17A (230-240Vdc, CCC only) |
| +12V Standby Output | Max: 2.1A |
| Power Supply Certification | Titanium Level 96% |
| Operating Temperature | |
| Operating Temperature | 10°C ~ 35°C (50°F ~ 95°F) |
| Non-operating Temperature | |
| Non-operating Temperature | -40°C to 60°C (-40°F to 140°F) |
| Operating Relative Humidity | |
| Operating Relative Humidity | 8% to 90% (non-condensing) |
| Non-operating Relative Humidity | |
| Non-operating Relative Humidity | 5% to 95% (non-condensing) |
| RoHS Compliance | |
| RoHS Compliance | RoHS Compliant |
